Titanium Gr 5 Tubing Manufacturer, Supplier and Exporter in Safat, Kuwait

Nestled in the industrial heart of Safat, Kuwait, Lathief Pipes stands as a trusted name for premium metal solutions. We take great pride in supplying high-performance Titanium Grade 5 Tubing to a wide range of industries. Known for its exceptional strength and reliability, this material is the go-to choice for projects where failure is not an option, ensuring that our clients’ operations are built on a foundation of quality and durability that truly stands the test of time.

Ti UNS R56400 Tubing In Kuwait, ASTM B338 Titanium Alloy Gr 5 Tubes In United kingdom, ASTM B338 Titanium Gr 5 Tubes Supplier In Safat, Titanium Gr 5 Tubing Exporter In West Safat, Ti Alloy DIN 3.7165 Tubes In Hawalli, Titanium Alloy Gr 5 Tubes Safat,Grade 5 Titanium Welded Tube Manufacturer in Nottingham.

When it comes to composition, Titanium Grade 5 is an alloy primarily composed of titanium, aluminum, and vanadium. This specific blend grants it an excellent strength-to-weight ratio, making it remarkably strong yet lightweight. In terms of mechanical properties, it offers impressive tensile strength and outstanding corrosion resistance, even in challenging environments. It also maintains its integrity across a wide range of temperatures, ensuring consistent performance whether the application calls for high heat or cryogenic conditions.

Titanium Gr 5 Tubing Specification

Specification : ASTM B861, B338, B388, B862 / ASME SB861, SB338, SB388, SB862
Pipe Range : ½”NB to 24”NB / SCH 10 – SCH XXS
Tubes Range: 1mm OD to 254mm OD / Thickness 0.1 to 20mm.
Type : Seamless / ERW / Welded / Fabricated Pipes
Form : Round, Square, Rectangular, Oval, Hydraulic Etc
Length : Single Random, Double Random & Required Length
End : Plain End, Beveled End, Treaded
Schedule : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
Inspection, Test Reports : Mill Test Certificates, EN 10204 3.1, Chemical Reports, Mechanical Reports, PMI Test Reports, Visual Inspection Reports, Third Party Inspection Reports, NABL Approved Lab Reports, Destructive Test Report, Non Destructive Test Reports
Packing : Packed in Wooden Boxes, Plastic Bags, Steel Strips Bundled, or as per Customers Requests
Specials : Sizes and Specifications other than above can be manufactured on request

Titanium Gr 5 Tubing Chemical Composition

Al	Fe	O	Ti	V
max	max	max	max	max
6	0.25	0.2	90	4

Titanium Gr 5 Tubing Mechanical Properties

Hardness, Brinell	334	334	Estimated from Rockwell C.
Hardness, Knoop	363	363	Estimated from Rockwell C.
Hardness, Rockwell C	36	36
Hardness, Vickers	349	349	Estimated from Rockwell C.
Tensile Strength, Ultimate	950 MPa	138000 psi
Tensile Strength, Yield	880 MPa	128000 psi
Elongation at Break	14 %	14 %
Reduction of Area	36 %	36 %
Modulus of Elasticity	113.8 GPa	16500 ksi
Compressive Yield Strength	970 MPa	141000 psi
Notched Tensile Strength	1450 MPa	210000 psi	K_t (stress concentration factor) = 6.7
Ultimate Bearing Strength	1860 MPa	270000 psi	e/D = 2
Bearing Yield Strength	1480 MPa	215000 psi	e/D = 2
Poisson’s Ratio	0.342	0.342
Charpy Impact	17 J	12.5 ft-lb	V-notch
Fatigue Strength	240 MPa	34800 psi	at 1E+7 cycles. K_t (stress concentration factor) = 3.3
Fatigue Strength	510 MPa	74000 psi	Unnotched 10,000,000 Cycles

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

ASTM B338 Grade 2 Titanium Tubing In Kuwait, UNS R56400 Tube Dealer In United kingdom, DIN 3.7165 Tubes Trader Safat, Ti Alloy Gr 5 Tubes In West Safat, ASME SB338 Titanium Alloy Gr 5 Tubes Stockist In Hawalli, Ti Grade 5 Tubing Safat,Grade 5 Titanium Tubing In Jahra, Titanium Alloy Gr.5 Tubes Supplier in Safat, Kuwait.

Why Choose Titanium Gr 5 Tubing from Lathief Pipes and Tubes?

By choosing Titanium Gr 5 Tubing from Lathief Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Titanium Gr 5 Tubing Supplier in Safat, Kuwait

Lathief Pipes and Tubes, a leading supplier of Titanium Gr 5 Tubing in Safat, Kuwait, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.

Ti UNS R56400 Tubes In Kuwait, ASTM B338 Titanium Alloy Gr 5 Tubing In United kingdom, ASTM B338 Titanium Gr 5 Tubing Supplier In Safat, Titanium Gr 5 Tubing Exporter In West Safat, Ti Alloy DIN 3.7165 Tubes In Hawalli, Titanium Alloy Gr 5 Tubing Safat,Grade 5 Titanium Welded Tube Manufacturer in Nottingham.

Types of Titanium Gr 5 Tubing

Are Custom Sizes Available for Titanium Gr 5 Tubing?

At Lathief Pipes and Tubes, we provide custom sizes of Titanium Gr 5 Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@brydonpipesandtubes.co.uk.

ASTM B338 Grade 2 Titanium Tubing In Kuwait, UNS R56400 Tube Dealer In United kingdom, DIN 3.7165 Tubes Trader Safat, Ti Alloy Gr 5 Tubing In West Safat, ASME SB338 Titanium Alloy Gr 5 Tubing Stockist In Hawalli, Ti Grade 5 Tubing Safat,Grade 5 Titanium Tubes In Jahra, Titanium Alloy Gr.5 Tubes Supplier in Safat, Kuwait.

You’ll find Titanium Gr 5 Tubing widely used in industries that demand lightweight strength and corrosion resistance. In aerospace, it’s utilized for engine components, airframes, and hydraulic systems, thanks to its high strength-to-weight ratio. The marine industry relies on it for offshore structures, ship components, and seawater cooling systems due to its resistance to saltwater corrosion. In the medical field, it’s used in implants, prosthetics, and surgical devices because of its excellent biocompatibility. Additionally, sectors like chemical processing, power generation, and automotive depend on it for heat exchangers, reactors, and high-performance systems that operate under extreme conditions.
