Nestled in the industrial heart of Safat, Kuwait, Lathief Pipes stands as a trusted name for excellence in metal fabrication. We take particular pride in our specialized Titanium Boiler Tubing, engineered to meet the most demanding conditions. Understanding that reliability is non-negotiable in critical systems, we provide tubing solutions that deliver unmatched longevity and performance, ensuring your operations run smoothly and efficiently, day in and day out. When your project requires the superior strength of titanium, our team is here to deliver.
The real strength of this tubing lies in its composition, primarily Grade 1 or Grade 2 titanium. This isn’t just any metal; it’s exceptionally resilient against pitting and crevice corrosion, especially from challenging chlorides. Mechanically, it maintains impressive strength at high temperatures while being surprisingly lightweight compared to many alternatives. This unique combination means it can handle high pressures and thermal cycling far better than traditional materials, reducing the risk of failure and ensuring a much longer, more reliable service life for your equipment.
| Standard | ASTM, AISI, GB, JIS, customers’ requests available |
| Size | Round Tube: OD: 16-119mm or customized |
| Thickness | 0.25mm-3.0mm |
| Length | 6m or according to customers’ request |
| Sample | Free sample is available, but freight should be paid by you |
Tolerance | Outer diameter: ±0.2mm |
| Thickness: ±0.05mm | |
| Length: ±0.5mm | |
| Ends | In plain end or beveled ends or as your requirements |
| Welding Line Type | ERW (Electrical Resistance Weld) |
Finishing | A. Sanded |
| B. Gloss #400,Mirror #600 – #1000 | |
| C. Brushed | |
| D. Wood Grain | |
| E. Embossed, Threaded | |
| Application | Decorations, constructions, food industry, etc. |
| Certification | ISO, SGS |
| Round Pipe Size | 16, 17, 18, 19, 20, 21, 22, 23, 25, 28, 31.8, 35, 36, 38.1, 48, 50.8, 60, 63.5, 76.2, 89, 101, 114 mm |
| Square Pipe Size | 17, 18, 19, 20, 21, 22, 23, 24, 25, 28, 30, 36, 38, 50 mm |
| Rectangle Pipe Size | 10*30, 10*40, 10*50, 20*10, 23*11, 24*12, 25*13, 28*25, 28*13, 29*14, 30*15, 30*20, 30*22, 34*22, 36*23, 50*25, 60*30, 75*45, 95*45 mm |
| Thickness | exact 0.25, 0.28, 0.32, 0.37, 0.41, 0.51, 0.61, 0.71, 0.91, 1.11, 1.15, 1.41 mm |
| Length | 6m or according to customer’s request |
| Outer diameter | 6.35-219mm |
| Tolerance | Outer diameter :±0.2mm |
| Thickness :±0.02mm | |
| Length :±0.5mm | |
| Process method | Code drawn, annealed with nitrogen protection, ultrasonic, automatic shape, polished |
| Test | Direct-reading Spectrograph, Hydrostatic testing machine, X-ray detector, UI trasonic flaw detector, Magnetic particle detector |
| Equipment | Press machine, Bending machine, Pushing Machine, electric bevelling machine Sand-blasting machine, etc |
| Origin | West Europe / Japanese / Indian / USA / Korean / American / European |
| Test Certificates | Manufacturer Test Certificate as per EN 10204 / 3.1B, Raw Materials Certificate, 100% Radiography Test Report, Third Party Inspection Report |
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Ti Grade2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Ti Grade5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Element | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Titanium Gr. 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Titanium Gr. 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
By choosing Titanium Boiler Tubing from Lathief Pipes and Tubes, you are assured of superior quality and durability. These tubes provide outstanding corrosion resistance and strength, making them ideal for a wide range of industrial applications. Our dedication to excellent service and dependable delivery ensures customer satisfaction every time. With our expertise in stainless steel products, we deliver top-tier solutions customized to meet your specific requirements.
Lathief Pipes and Tubes, a leading supplier of Titanium Boiler Tubing in Safat, Kuwait, provides a wide selection of premium pipes and tubes for diverse industrial applications. With a vast inventory and a strong focus on delivering outstanding service, they are the preferred choice for stainless steel products in the region.
At Lathief Pipes and Tubes, we provide custom sizes of Titanium Boiler Tubing to meet your exact specifications. Our dedicated team is here to offer tailored solutions for all your piping and tubing needs. For more information, feel free to reach out to us at sales@lathiefpipes.com.
This Titanium Boiler Tubing finds extensive use in industries that demand high corrosion resistance, heat resistance, and long-term reliability. In power plants, it’s utilized in boiler tubes, superheaters, and heat exchangers due to its ability to handle high temperatures and pressures without compromising quality. The chemical and petrochemical sectors rely on it for process heating and evaporators where corrosion resistance is paramount. In marine settings, it’s used in seawater boilers and desalination plants thanks to its remarkable resistance to saltwater corrosion. Its long service life, durability, and efficiency make it an exceptional choice for these applications.
