Home > Stainless Steel > Stainless Steel Square Pipes
Nestled in the industrial heart of Safat, Kuwait, Lathief Pipes stands as a trusted name for quality and durability. We specialize in crafting superior Stainless Steel Square Pipes, designed to meet the rigorous demands of modern industry. Our commitment goes beyond supply; we provide reliable, long-lasting solutions for a diverse range of applications. When you choose Lathief Pipes, you are selecting a partner dedicated to excellence and the enduring strength that our products are known for.
These square pipes are primarily composed of austenitic stainless steel grades, often 304 or 316, which provide a remarkable blend of strength and corrosion resistance. The inherent properties of the material, including excellent tensile strength and durability, are enhanced by the square profile. This shape offers superior structural support and torsion resistance compared to other forms. The clean, sharp lines not only contribute to strength but also make them ideal for visible applications where aesthetics matter.
| Pipe Size | 12.75 X 12.75, 15 X 15, 20 X 20, 25 X 25, 30 X 30, 40 X 40, 50 X 50, 60 X 60, 75 X 75, 80 X 80, 90 X 90, 100 X100 |
| Grades | TP – 304/L/H, TP – 316/L/H/Ti, TP – 317L, TP – 321/H, TP – 347/H, 202, JT – 7, J4 – 1, TP – 409/L, TP – 410, TP – 430Ti, TP 439 |
| Standards | ASTM A249 – A269 – A312 – A358 – A409 – A554 – A778 – A789 – A790 |
| TOLERANCE on Length | Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm |
| Finish | Polished Grit 120 – 600, Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm,Mirror Polished |
Hollow Sections:
Square:10 mmx10mm – 500 mmx500mm
Retangular:10mm x 20mm – 600mmx400mm
Round: 1/8″ – 4″
Wall Thickness: 0.5 – 20.0mm
Length:0.3 mtr – 18 mtr as customer required
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing stainless steel square pipes from Lathief Pipes and Tubes ensures high-quality materials with excellent corrosion resistance and durability. Our products are tailored to meet diverse industry standards, offering reliability and versatility for various applications. Our commitment to customer service and timely delivery makes us a trusted supplier.
Lathief Pipes and Tubes, one of the largest suppliers of Stainless Steel Square Pipes in Safat, Kuwait, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Outside Diameter | Qty/B | 0.6 | 0.7 | 0.8 | 0.9 | 1.0 | 1.2 | 1.5 | 2.0 | 3.0 | 4.0 | 5.0 | 6.0 | |
|---|---|---|---|---|---|---|---|---|---|---|---|---|---|---|
| Inches | mm | Lgh | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs | Kgs |
| 3/8″ | 9.5 | 100 | 0.81 | 0.94 | 1.06 | 1.18 | 1.29 | 1.51 | 1.82 | |||||
| 1/2″ | 12.7 | 100 | 1.10 | 1.28 | 1.45 | 1.61 | 1.78 | 2.10 | 2.55 | |||||
| 5/8″ | 15.9 | 100 | 1.39 | 1.62 | 1.84 | 2.05 | 2.26 | 2.68 | 3.28 | |||||
| 3/4″ | 19.1 | 100 | 1.69 | 1.96 | 2.22 | 2.49 | 2.75 | 3.26 | 4.01 | |||||
| 7/8″ | 22.2 | 100 | 1.97 | 2.29 | 2.60 | 2.91 | 3.22 | 3.83 | 4.72 | |||||
| 1″ | 25.4 | 100 | 2.26 | 2.63 | 2.99 | 3.35 | 3.71 | 4.41 | 5.45 | |||||
| 11/8″ | 28.6 | 50 | 2.55 | 2.97 | 3.38 | 3.79 | 4.19 | 5.00 | 6.18 | |||||
| 11/4″ | 31.8 | 50 | 2.84 | 3.31 | 3.77 | 4.23 | 4.68 | 5.58 | 6.91 | |||||
| 11/2″ | 38.1 | 50 | 3.42 | 3.98 | 4.53 | 5.09 | 5.64 | 6.73 | 8.34 | |||||
| 15/8″ | 41.3 | 50 | 3.71 | 4.32 | 4.92 | 5.52 | 6.12 | 7.31 | 9.07 | |||||
| 13/4″ | 44.5 | 50 | 4.00 | 4.66 | 5.31 | 5.96 | 6.61 | 7.90 | 9.80 | |||||
| 2″ | 50.8 | 10 | 6.08 | 6.82 | 7.57 | 9.04 | 11.24 | 14.83 | 21.79 | |||||
| 21/2″ | 63.5 | 10 | 7.62 | 8.56 | 9.50 | 11.36 | 14.13 | 18.69 | 27.58 | |||||
| 3″ | 76.2 | 10 | 9.17 | 10.30 | 11.43 | 13.68 | 17.03 | 22.55 | 33.37 | 43.88 | ||||
| 31/2″ | 88.9 | 10 | 10.71 | 12.03 | 13.36 | 15.99 | 19.92 | 26.41 | 39.16 | 51.60 | ||||
| 4″ | 101.6 | 10 | 18.31 | 22.82 | 30.27 | 44.95 | 59.32 | 73.39 | 87.16 | |||||
| 5″ | 127 | 10 | ||||||||||||
| 6″ | 152.4 | 10 | ||||||||||||
Yes, we offer custom sizes for Stainless Steel Square Pipes to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
Stainless Steel Square Pipes find extensive use in construction and structural projects, serving as support frameworks, columns, and handrails. Their smooth finish and resistance to corrosion make them a great choice for furniture manufacturing, architectural designs, and decorative features. Additionally, they are employed in automotive components, marine applications, and various engineering projects due to their impressive strength-to-weight ratio. In the food processing and pharmaceutical industries, these pipes are also favored for their hygienic properties and durability, making them a versatile option across multiple sectors.
