Home > Stainless Steel > Stainless Steel 439 Tubing
For those in Safat and across Kuwait seeking unwavering quality in industrial tubing, Lathief Pipes stands as your trusted local source. We take pride in supplying premium Stainless Steel 439 Tubing, a material specifically engineered for challenging environments. Known for its excellent resistance to corrosion and high temperatures, this tubing offers a reliable and cost-effective solution for a wide array of demanding projects, ensuring longevity and performance you can count on right here in the region.
The strength of Stainless Steel 439 lies in its thoughtful composition, which includes a healthy level of chromium for a protective layer and the addition of titanium for superior stability. This specific formulation grants it impressive mechanical properties, including good formability and weldability, making it easier to work with during fabrication. It maintains admirable strength and durability, even when faced with thermal stress, providing a robust material that consistently performs under pressure.
| GRADES | TP 439 Stainless Steel Tubes / UNS S43035 / DIN 1.4510 |
| SIZE | 1/2″ NB to 24″ NB |
| STANDARDS | ASTM A213, ASTM A249, ASTM A554, ASTM A269, ASTM A270, ASTM A790, ASTM A789 |
| TYPE | Seamless Tubes, Welded Tubes, EFW Tubes, ERW Tubes, Fabricated Tubes, Cold Drawn Welded Tubes (CDW Tubes) |
| FORM | Round Tubes, Square Tubes, Rectangular Tubes, Oval Tubes, Hydraulic Tube, etc. |
| END | Plain End, Treaded, Beveled End |
| TOLERANCE on Length | Commercial Length: 6000mm +/- 30mm Fix Length: from 1200 mm up to 12000mm with a tolerance up to -0/+ 5mm |
| FINISH | Seamless, Welded, Brushed, Pickled, Solution Annealed and Pickled up to O.D. 219.1mm, Polished Grit 120 – 600, Mirror Polished |
|
Grade |
WERKSTOFF NR. |
UNS |
|
SS 439 |
1.4510 |
S43035 |
|
Grade |
Fe |
Cr |
Si |
Ti |
Mn |
Ni |
Mo |
Nb/Cb |
P |
N |
C |
S |
|
SS 439 |
81.3535 |
17.35 |
0.35 |
0.335 |
0.25 |
0.200 |
0.1 |
0.02 |
0.02 |
0.0100 |
0.01 |
0.0015 |
Tensile strength (annealed) | 438 MPa | 63500 psi |
Yield strength (annealed/ @strain 0.200 %) | 263 MPa | 38100 psi |
Modulus of elasticity | GPa | ksi |
Poisson’s ratio | 0.270 – 0.290 | 0.270 – 0.290 |
Elongation at break (In 2″, 50% cold worked) | 2.80% | 2.80% |
Hardness, Rockwell B (annealed) | 72.9 | 72.9 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 439 Tubing from Lathief Pipes and Tubes ensures high quality materials that resist corrosion and heat. Their materials offer excellent weldability, low risk of intergranular damage, and durability in tough materials. Lathief offers precision engineered tubing with strict quality control, ensuring reliability in the automotive, industrial and construction industries. Their customer service, competitive pricing and on-time delivery make them a trusted provider of stainless steel specialty solutions.
Lathief Pipes and Tubes, one of the largest suppliers of Stainless Steel 439 Tubing in Safat, Kuwait, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Wall | Sizes ( O.D.) |
|---|---|
| .010 | 1/16″ , 1/8″ , 3/16″ |
| .020 | 1/16″ , 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ |
| .012 | 1/8″ |
| .016 | 1/8″ , 3/16″ |
| .028 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 3/4″ , 1″ , 1 1/2″ , 2″ |
| .035 | 1/8″ , 3/16″ , 1/4″ , 5/16″ , 3/8″ , 7/16″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .049 | 3/16″ , 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/8″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 2″ , 2 1/4″ |
| .065 | 1/4″ , 5/16″ , 3/8″ , 1/2″ , 16″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 3/4″ , 2″ , 2 1/2″ , 3″ |
| .083 | 1/4″ , 3/8″ , 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 1 5/8″ , 1 7/8″ , 2″ , 2 1/2″ ,3″ |
| .095 | 1/2″ , 5/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .109 | 1/2″ , 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ |
| .120 | 1/2″ , 5/8″ , 3/4″ , 7/8″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 2 1/4″ , 2 1/2″ , 3″ |
| .125 | 3/4″ , 1″ , 1 1/4″ , 1 1/2″ , 2″ , 3″ , 3 1/4″ |
| .134 | 1″ |
| .250 | 3″ |
| .375 | 3 1/2″ |
| Density (lb./ in^2) @ RT | 0.278 | |
|---|---|---|
| Modulus of Elasticity in Tension (psi x 10^6) | 29.0 | |
| Specific Heat (BTU/o F/lb.) | 32 to 212 oF | 0.11 |
| Thermal Conductivity (BTU/hr/ft^2/ft) | 212oF | 168.0 |
| Mean Coefficient of Thermal Expansion (in. x 10^-6 per o F) | 32 to 212oF | 5.6 |
| 32 to 932oF | 6.4 | |
| 32 to 1,472oF | 6.9 | |
| Electrical Resistivity (micro ohms – cm) | at 70oF | 63 |
| Oxidation Resistance – Continuous Service(oF) | 1700 |
Stainless Steel 439 Tube OD | Stainless Steel 439 Tube Tolerance |
|---|---|
4mm to 35mm | +/- 0.08mm |
35mm to 38mm | +/- 0.15mm |
38mm to 60mm | +/- 0.20mm |
60mm and above | +/- 0.25mm |
Yes, we offer custom sizes for Stainless Steel 439 Tubing to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
Stainless Steel 439 Tubing is widely used across various industries thanks to its exceptional corrosion resistance and strength. In the automotive sector, it’s commonly found in exhaust systems, catalytic converters, and heat exchangers. In construction and architectural projects, it serves as structural support, cladding, and decorative elements due to its durability and appealing finish. Additionally, it’s utilized in chemical and petrochemical processing equipment, food processing machinery, and water treatment facilities. Its weldability and cost-effectiveness further establish it as an ideal choice for manufacturing applications.
