Home > Stainless Steel >Stainless Steel 420 Pipes
Nestled in the industrial heart of Safat, Kuwait, Lathief Pipes has built a strong reputation as a trusted source for high-grade piping solutions. We take particular pride in our Stainless Steel 420 Pipes, a product line known for its remarkable durability and performance. We understand that our clients require materials that can withstand demanding conditions, which is why we ensure our 420 pipes are manufactured to the highest standards, offering a reliable choice for a wide array of industrial and engineering projects across the region and beyond.
The strength of Stainless Steel 420 comes from its specific makeup, centered around a martensitic structure with a key emphasis on chromium. This composition is the secret to its notable hardness and impressive strength, especially after a proper heat treatment process. While it offers good resistance to corrosion in milder environments, its true calling card is its ability to resist wear and abrasion exceptionally well. This combination of mechanical toughness makes it a go-to material for applications where durability is non-negotiable.
| Specifications | ASTM A312, A358 / ASME SA312, SA358 |
|---|---|
| Dimensional Specification | ANSI/ASME B36.19M, ANSI/ASME B36.10M |
| Seamless Pipe Size | 1 / 8″ NB – 24″ NB |
| Welded Pipe Size | 1 / 8″ NB – 24″ NB |
| EFW Pipe Size | 6″ NB – 48″ NB |
| Outside Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB available Ex-stock, OD Size Steel Tubes available Ex-stock |
| Manufacturing Shapes | Hydraulic, Round, Rectangle, Square, Hex, Honed |
| Manufacturing Techniques | Seamless / Welded / ERW / Fabricated / CDW / 100% X Ray Welded |
| Schedule Thickness Range | SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| End Types | Plain End, Beveled End, Treaded One End, TBE (Treaded Both Ends) |
| Inspection and Test Reports | EN 10204 3.1, Mill Test Certificates, Chemical Reports, PMI Test Reports, Mechanical Reports, Third Party Inspection, NABL Approved Lab, Visual Inspection, Destructive Test and Non Destructive Test Reports |
| Grade | C | Mn | Si | P | S | Cr | MO | Ni | CU | |
| 420 | Min | – | – | – | – | – | 12.0 | – | – | – |
| max | 0.15 | 1.00 | 1.00 | 0.04 | 0.03 | 14.0 | – | – | – |
| Grade | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) | Brinell (HB) | ||||
| 420 | 95,000 | 50,000 | 25 | – | 175 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 420 Pipes from Lathief Pipes and Tubes ensures quality and reliability. Our products are rigorously tested and meet stringent industry standards, guaranteeing exceptional performance. We offer customized solutions to meet the specific needs of the business. By focusing on innovation, our pipes have increased their corrosion resistance and durability. Additionally, our experienced team provides excellent customer support, ensuring a seamless experience from order to delivery. Trust Lathief for your stainless steel needs, where quality meets best.
Lathief Pipes and Tubes, one of the largest suppliers of Stainless Steel 420 Pipes in Safat, Kuwait, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| STANDARD | WERKSTOFF NR. | UNS | JIS | BS | EN |
|---|---|---|---|---|---|
| SS 420 | 1.4021 | S42000 | SUS 420J1 | 420S29 | X20Cr13 |
| Grade | Density (kg/m3) | Elastic Modulus (GPa) | Mean Coefficient of Thermal Expansion (μm/m/°C) | Thermal Conductivity (W/m.K) | Specific Heat 0-100°C (J/kg.K) | Electrical Resistivity (nΩ.m) | |||
| 0-100°C | 0-315°C | 0-538°C | at 100°C | at 500°C | |||||
| 420 | 7900 | 300 | 11.5 | 11.8 | 11.9 | 25.9 | – | 480 | 570 |
Yes, we offer custom sizes for Stainless Steel 420 Pipes to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
You’ll find Stainless Steel 420 Pipes hard at work in many critical areas. They are a common sight in the cutlery industry for knife blades and professional kitchen equipment, and they are equally vital for manufacturing industrial parts like pins, shafts, and fasteners that must endure constant friction. Their reliable performance also makes them a suitable choice for components in pumps and valves, as well as in the medical field for specific surgical and dental instruments, where their strength and cleanability are essential.
