Home > Stainless Steel >Stainless Steel 301L Pipes
Nestled in the industrial heart of Safat, Kuwait, Lathief Pipes has built a solid reputation as a trusted manufacturer and supplier, with a particular expertise in high-grade Stainless Steel 301L Pipes. We understand that the integrity of your project depends on the quality of its components, which is why we ensure our 301L pipes are crafted to meet the most demanding specifications, providing a reliable foundation for critical applications across various industries.
The composition of Stainless Steel 301L includes chromium, nickel, and a low carbon content, which gives these pipes excellent corrosion resistance. Mechanically, they are known for their high strength and good durability, making them tough enough to handle significant stress. This combination also allows for better weldability, so the pipes maintain their integrity even under challenging conditions.
| Item | Stainless Steel 301L Pipe |
|---|---|
| Standard | GB, AISI, ASTM, ASME, EN, BS, DIN, JIS |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Outer Diameter Size | SEAMLESS – 1/2″ NB TO 18″ NB WELDED / ERW- 1″ NB TO 16″ NB EFW – 8″ NB TO 110″ NB |
| Form | Round Pipes, Square Pipes, Rectangular Pipe, “U” Shape Pipes, Hydraulic Pipes |
| Wall Thickness | Schedule 10 To Schedule 160 (3 mm to 100 mm Thickness) |
| Length | 01 Meter to 12.5 Meters, Single Random Length, Double Random Length And Customize Size End: Plain End, Beveled End, Treaded |
| Delivery Conditions | As Rolled, Formed, Stress Relieved, Annealed, Hardened, Tempered, Cold Draw |
| Coating | Electropolish, Mechanical Polish, Satin Finish, Passivated |
| Testing | Product Analysis, Transverse Tension Test, Flattening Test, Etching Test, Radiographic Examination, Stabilizing Heat Treatment, Intergranular Corrosion Test, Weld Decay Test, Magnetic Particle Detection, Grain Size Test, NACE 0175, Dual Grade, PWHT (POST WELD HEAT TREATMENT), Flare Test, Bend Test, Hardness Test, Tensile Test etc |
| Dimension | All Pipes Is Manufactured and Inspected / Tested to the Relevant standards including ASTM and ASME |
| Value Added Services | Draw / Expansion / Machining / Sand Blasting / Shot Blasting / Heat Treatment |
| Packaging | Loose / Bundle / Wooden Pallet / Wooden Box / Plastic Cloth Wraps / Plastic End Caps / Beveled Protector |
| Material Test Certificate | Manufacturer Test Certificate As Per EN10204 3.1, 3.2 / Laboratory Test Certificate From NABL Approved Lab. / Under Third Party Inspection Agency Like SGS, TUV, DNV, LLOYDS, ABS ETC |
| Grade | C | Mn | Si | P | S | Cr | N | Ni |
| SS 301L | 0.03 max | 2.0 max | 1.00 max | 0.045 max | 0.030 max | 16.0 – 18.0 | 0.10 max | 6.00 – 8.00 |
| Grade | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| SS 301L | 515 | 205 | 40 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel 301L Pipes from Lathief Pipes and Tubes ensures you get the high quality products you need. Our pipe is made from premium materials, providing exceptional strength and corrosion resistance. With extensive industry experience, we put customer satisfaction first, and provide expert guidance throughout the selection process. We offer competitive pricing and strict quality control to meet international standards. Additionally, our commitment to on-time delivery ensures that your services are delivered on time. Trust Lathief for reliable, high-performance plumbing solutions that will stand the test of time.
Lathief Pipes and Tubes, one of the largest suppliers of Stainless Steel 301L Pipes in Safat, Kuwait, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
| Pipe Size | O.D. inches | Pipe Schedule | |||||||
|---|---|---|---|---|---|---|---|---|---|
| 5 | 10 | 40 | STD | 80 | XH | 160 | XXH | ||
| 1/8 | 0.405 | .1383 | .1863 | .2447 | .2447 | .3145 | .3145 | ||
| 1/4 | 0.540 | .2570 | .3297 | .4248 | .4248 | .5351 | .5351 | ||
| 3/8 | 0.675 | .3276 | .4235 | .5676 | .5676 | .7388 | .7388 | ||
| 1/2 | 0.840 | .5380 | .6710 | .8510 | .8510 | 1.088 | 1.088 | 1.304 | 1.714 |
| 3/4 | 1.050 | .6838 | .8572 | 1.131 | 1.131 | 1.474 | 1.474 | 1.937 | 2.441 |
| 1 | 1.315 | .8678 | 1.404 | 1.679 | 1.679 | 2.172 | 2.172 | 2.844 | 5.214 |
| 1-1/4 | 1.660 | 1.107 | 1.806 | 2.273 | 2.273 | 2.997 | 2.997 | 3.765 | 5.214 |
| 1-1/2 | 1.900 | 1.604 | 2.085 | 2.718 | 2.718 | 3.631 | 3.631 | 4.859 | 6.408 |
| 2 | 2.375 | 1.604 | 2.638 | 3.653 | 3.653 | 5.022 | 5.022 | 7.444 | 9.029 |
| 2-1/2 | 2.875 | 2.475 | 3.531 | 5.793 | 5.793 | 7.661 | 7.661 | 10.01 | 13.69 |
| 3 | 3.500 | 3.029 | 4.332 | 7.576 | 7.576 | 10.25 | 10.25 | 14.32 | 18.58 |
| 3-1/2 | 4.000 | 3.472 | 4.973 | 9.109 | 9.109 | 14.98 | 12.50 | 22.85 | |
| 4 | 4.500 | 3.915 | 5.613 | 10.79 | 10.79 | 14.98 | 14.98 | 22.51 | 27.54 |
| 5 | 5.563 | 6.349 | 7.770 | 14.62 | 14.62 | 20.78 | 20.78 | 32.96 | 38.55 |
| 6 | 6.625 | 7.585 | 9.289 | 18.97 | 18.97 | 28.57 | 28.57 | 45.30 | 53.16 |
| 8 | 8.625 | 9.014 | 13.40 | 28.55 | 28.55 | 43.39 | 43.39 | 74.69 | 72.42 |
| 10 | 10.750 | 15.19 | 18.70 | 40.48 | 40.48 | 64.33 | 54.74 | ||
| 12 | 12.750 | 20.93 | 24.16 | 53.52 | 49.56 | 88.51 | 65.42 | ||
| 14 | 14.000 | 42.05 | 63.37 | 54.57 | 106.1 | 72.09 | |||
| 16 | 16.000 | 42.05 | 82.77 | 62.58 | 136.5 | 82.77 | |||
| 18 | 18.000 | 47.39 | /104.8 | 70.59 | 170.8 | 93.45 | |||
| 20 | 20.000 | 52.73 | 122.9 | 78.60 | 208.9 | 104.1 | |||
| 24 | 24.000 | 63.41 | 171.2 | 94.62 | 296.4 | 125.50 | |||
Yes, we offer custom sizes for Stainless Steel 301L Pipes to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
Stainless Steel 301L Pipes find extensive use in process piping, exhaust systems, heat exchangers, and structural applications that require corrosion resistance, mechanical strength, and formability. They are also utilized in chemical and petrochemical plants, power generation, marine settings, and the food and beverage processing sectors. Furthermore, they are ideal for HVAC systems, instrumentation lines, and industrial piping where long-term durability, leak-free operation, and reliability are crucial. The blend of corrosion resistance, strength, and weldability makes Stainless Steel 301L Pipes a fantastic option for demanding industrial and commercial applications.
