Home > Duplex Steel > Duplex Steel EFW Pipes
Lathief Pipes, based in Safat, Kuwait, is a leading manufacturer and supplier of high-quality piping solutions for demanding industrial environments. Their Duplex Steel EFW (Electric Fusion Welded) Pipes are designed to deliver exceptional strength, durability, and corrosion resistance, making them ideal for critical industrial applications. Engineered with precision, these pipes perform reliably under high pressure, fluctuating temperatures, and exposure to aggressive chemicals. Lathief Pipes prioritizes quality, consistency, and customer satisfaction, making Duplex Steel EFW Pipes a preferred choice for industries such as oil and gas, petrochemical, desalination, and marine engineering across Kuwait and the surrounding region.
Duplex Steel EFW Pipes are made from a high-performance duplex stainless steel alloy with balanced ferritic and austenitic microstructure, enriched with chromium, nickel, and molybdenum. This combination provides outstanding resistance to pitting, crevice corrosion, and stress corrosion cracking. Mechanically, these pipes offer excellent tensile and yield strength, toughness, and fatigue resistance, while maintaining dimensional stability under high pressure and thermal cycling. The EFW manufacturing process ensures uniform wall thickness, precise dimensions, and smooth surfaces, resulting in robust, reliable pipes suitable for demanding industrial environments requiring both strength and corrosion resistance.
| ASTM Specification | ASTM A790 ASME SA790 |
|---|---|
| Applicable Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| Size | 4 to 219mm W. T.: 0.5 to 20mm |
| Welded Pipe Size | 5.0 – 1219.2 mm |
| EFW Pipe size | 5.0 – 1219.2 mm |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Schedule | SCH5, SCH10, SCH10S, SCH20, SCH30, SCH40, SCH40S, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS |
| Length | Single Random, Double Random, Standard & Cut length Pipe |
| Form | Duplex 2205 Pipe are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Type | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Duplex 2205 Pipe |
| Pipe End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Application | Dairy Pipe, Oil Pipe, Gas Pipe, Fluid Pipe, Boiler Pipe for Chemical Industry |
| 13.72 | 1.65 | 1/4 | 10S | 0.50 |
| 13.72 | 2.24 | 1/4 | 40S | 0.64 |
| 13.72 | 3.02 | 1/4 | 80S | 0.81 |
| 17.15 | 1.65 | 3/8 | 10S | 0.64 |
| 17.15 | 2.31 | 3/8 | 40S | 0.86 |
| 17.15 | 3.20 | 3/8 | 80S | 1.12 |
| 21.34 | 2.11 | 1/2 | 10S | 1.02 |
| 21.34 | 2.77 | 1/2 | 40S | 1.29 |
| 21.34 | 3.73 | 1/2 | 80S | 1.65 |
| 26.67 | 2.11 | 3/4 | 10S | 1.30 |
| 26.67 | 2.87 | 3/4 | 40S | 1.71 |
| 26.67 | 3.91 | 3/4 | 80S | 2.23 |
| 33.40 | 2.77 | 1 | 10S | 2.13 |
| 33.40 | 3.38 | 1 | 40S | 2.54 |
| 33.40 | 4.55 | 1 | 80S | 3.29 |
| 33.40 | 6.352) | 1 | 160 | 4.30 |
| 42.16 | 2.77 | 1¼ | 10S | 2.73 |
| 42.16 | 3.56 | 1¼ | 40S | 3.44 |
| 42.16 | 4.85 | 1¼ | 80S | 4.53 |
| 42.16 | 6.352) | 1¼ | 160 | 5.69 |
| 48.26 | 2.77 | 1½ | 10S | 3.16 |
| 48.26 | 3.68 | 1½ | 40S | 4.11 |
| 48.26 | 5.08 | 1½ | 80S | 5.49 |
| 60.33 | 2.77 | 2 | 10S | 3.99 |
| 60.33 | 3.91 | 2 | 40S | 5.52 |
| 60.33 | 5.54 | 2 | 80S | 7.60 |
| 60.33 | 8.742) | 2 | 160 | 11.29 |
| 73.03 | 3.05 | 2½ | 10S | 5.35 |
| 73.03 | 5.16 | 2½ | 40S | 8.77 |
| 73.03 | 7.01 | 2½ | 80S | 11.59 |
| 88.90 | 3.05 | 3 | 10S | 6.56 |
| 88.90 | 5.49 | 3 | 40S | 11.47 |
| 88.90 | 7.62 | 3 | 80S | 15.51 |
| 88.90 | 11.132) | 3 | 160 | 21.67 |
| 101.60 | 3.05 | 3½ | 10S | 7.53 |
| 101.60 | 5.74 | 3½ | 40S | 13.78 |
| 101.60 | 8.08 | 3½ | 80S | 18.92 |
| 114.30 | 3.05 | 4 | 10S | 8.50 |
| 114.30 | 6.02 | 4 | 40S | 16.32 |
| 114.30 | 8.56 | 4 | 80S | 22.67 |
| 114.30 | 13.492) | 4 | 160 | 34.05 |
| 141.30 | 6.55 | 5 | 40S | 22.10 |
| 141.30 | 9.53 | 5 | 80S | 31.44 |
| 141.30 | 15.882) | 5 | 160 | 49.87 |
| 168.28 | 3.4 | 6 | 10S | 14.04 |
| 168.28 | 7.11 | 6 | 40S | 28.69 |
| 168.28 | 10.97 | 6 | 80S | 43.21 |
| 168.28 | 14.27 | 6 | 120 | 54.75 |
| 168.28 | 18.262) | 6 | 160 | 68.59 |
| 219.08 | 8.18 | 8 | 40S | 43.20 |
| 219.08 | 12.7 | 8 | 80S | 65.63 |
| 219.08 | 18.23 | 8 | 120 | 91.30 |
| 219.08 | 23.012) | 8 | 160 | 112.97 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
| Duplex Steel | C | N | P | Si | Mn | Mo | Fe | Cr | S | Ni |
| 1.0 | 0.03 | 0.02 | 2.0 | 3.0 – 3.5 | 22.0 – 23.0 | 0.03 | 4.5 – 6.5 | 0.14 – 0.2 | Bal |
| Duplex Steel | Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 7.8 g/cm3 | 1350 °C (2460 °F) | Psi – 80000 , MPa – 550 | Psi – 116000 , MPa – 800 | 15 % |
Choosing Duplex Steel EFW Pipes from Lathief Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Duplex Steel EFW Pipes are widely used in industries that demand high-strength, corrosion-resistant piping solutions. They are ideal for offshore and onshore oil and gas pipelines, chemical processing plants, petrochemical facilities, desalination units, and marine applications. These pipes perform exceptionally well in high-pressure systems, heat exchangers, seawater handling, and other environments exposed to corrosive chemicals or chloride-rich media. With superior mechanical properties, durability, and corrosion resistance, Duplex Steel EFW Pipes provide reliable, long-lasting performance, making them a trusted solution for industrial applications where safety, efficiency, and strength are critical.
Yes, we offer custom sizes for Duplex Steel EFW Pipes to meet your specific requirements. Our team at Lathief Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@lathiefpipes.com.
Duplex Steel EFW Pipes find extensive use in industries that require high corrosion resistance and mechanical strength. They’re commonly used in chemical and petrochemical plants for the safe transport of acids, alkalis, and other aggressive chemicals. In the oil and gas industry, these pipes are essential for pipelines, heat exchangers, and process equipment that come into contact with seawater and corrosive substances. Power generation facilities utilize them in boilers, condensers, and high-temperature systems, while marine industries depend on them for offshore structures and seawater handling applications. Their versatility and reliability make them a go-to choice for various demanding applications.
